Detail Information

Name:	Plastic Roof Tile Machine	Plastic Processed:	PVC, ABS
Application:	Sheet, Profile	Screw Design:	Double-screw
Twin Screw Type:	Counter-rotating Conical Twin-screw	Screw Material:	38CrMoALA
Screw Diameter (mm):	80 Mm	Screw L/d Ratio:	28:1
Screw Speed (rpm):	45	Place Of Origin:	China
Brand Name:	DEERMA	Voltage:	Customized
Dimension(lwh):	2553.5m	Power (kw):	250
Warranty:	1 Year	Key Selling Points:	High Productivity
Video Outgoing-inspection:	Provided	Core Components:	Motor, Pump, Gear, PLC, Engine, Gearbox
Machinery Test Report:	Provided	Weight (KG):	4500
Extruder Type:	Twin Screw	Machine Name:	PVC Hollow Wave Roof Tile Manufacturer Machine / Making Machine
Raw Material:	PVC Powder	Product Type:	Roof Tile
Motor:	SIEMENS Brand	Inverter:	ABB Frequency Controller
Contactor:	France SCHNEIDER Contactors	Temperature Controller:	Omron Brand
Automatic Grade:	Automatic	PVC Hollow Roof:	Width:832mm; Thickness: 11.8mm
Output (kg/h):	350 - 400 Kg/h
Highlight:	Customized Plastic Roof Tile Machine , Plastic Roof Tile Machine 350kg/h , 400kg/h Roofing Sheet Making Machine

Product Description

Top-Notch PVC Hollow Wave Roof Tile Machine With France SCHNEIDER Contactors And PVC Powder Raw Material

Product Description

Product Application

Machine name: Plastic PVC Hollow Roof Tile Making machine
Finshed product : Plastic Hollow roofing , PVC composite roofing , Plastic corrugated roofing, Double Wall roofing

Product application: Plastic Corrugated tile are used for Roofing, can be used for factories, warehouses, sheds, farmers market, hoardings, walls, temporary shops, sheds and other very suitable insulation

Product features:
PVC+ASA glazed/corrugated hollow composite resin tile should be the IDEAL REPLACEMENT of conventional asbestos and metal G.I. sheets which are not resistant to corrosion and weather under the high cost and short service life.
This new PVC composite roof tile production adopted advanced multilayer CO-EXTRUSION technology which well combine the different functions of raw materials(PVC+ASA) so that the tile can be anti-corrosive, fire retardant, eco-friendly, more durable, tenacious, easy to install and move, light weight as well as cost effective in installation (as less steel and less overlap), as per the efficiency and benefits it provides.
Apart from its numerous benefits, its salient features include heat insulation up to 35% (highly energy efficient) and it can withstand temperature up to 70 degrees Celsius to - 40 degrees Celsius which is very much suitable for YOUR MARKET.

Machine List
No.	Name	Qty.	Remark
1	Screw loader for SJZ 80/156 extruder	1
2	SJZ 80/156 conical twin-screw extruder	1	For the PVC layer
3	Vacuum loader for SJ50 extruder	1
4	Drying hopper for SJ50 extruder	1
5	SJ50/30 single screw extruder(ASA)	1	For the ASA layer
6	Mould unit	1
7	Distributor	1
8	Forming table and calibration mould	1
9	Haul off unit	1
10	Cutter	1
11	Stacker	1

1. SJSZ-80/156 conical twin screw extruder with Automatic Feeding system

2. PVC Hollow Roof Mould

3.Vacuum calibration platform

4. Haul- off Machine & cutter machine

Auxiliary Machine
12	Crusher	1	Power:11kw,22kw,30kw
13	Pulverizer	1	Power:45kw,55kw,75kw
14	SRL-Z300/600 Mixer unit	1	Capacity : 450-550kg/h
15	Screw loader for SRL-Z 300/600 Mixer	1

ELECTRIC BRAND SHOW

Packaging & Shipping

Customized Plastic Roof Tile Machine 350kg/h - 400kg/h Roofing Sheet Making Machine 11

Certifications

Customized Plastic Roof Tile Machine 350kg/h - 400kg/h Roofing Sheet Making Machine 12
