Detail Information

Name:	PVC Roof Tile Machine	Plastic Processed:	PVC, ABS
Application:	Sheet	Screw Design:	Double-screw
Twin Screw Type:	Counter-rotating Conical Twin-screw	Screw Material:	38CrMoALA
Screw Diameter (mm):	80 Mm	Screw L/d Ratio:	28:1
Screw Speed (rpm):	55	Place Of Origin:	China
Brand Name:	DEERMA	Voltage:	Customized
Dimension(lwh):	2553.5m	Power (kw):	250
Warranty:	1 Year	Key Selling Points:	High Productivity
Video Outgoing-inspection:	Provided	Core Components:	Bearing, Motor, Pump, Gear, PLC, Engine, Gearbox
Machinery Test Report:	Provided	Weight (KG):	3800
Extruder Type:	Twin Screw	Machine Name:	UPVC PVC Twin Wall Hollow Roof Machine
Raw Material:	PVC Powder	Motor:	SIEMENS Brand
Inverter:	ABB Frequency Controller	Contactor:	France SCHNEIDER Contactors
Temperature Controller:	Omron Brand	Automatic Grade:	Automatic
PVC Hollow Roof:	Width:832mm; Thickness: 11.8mm	Output (kg/h):	350 - 400 Kg/h
Highlight:	250kw PVC Roof Tile Machine , Automatic Roof Tile Manufacturing Machine , Roof Tile Manufacturing Machine Customized

Product Description

38CrMoALA Screw Material High Productivity UPVC PVC Twin Wall Hollow Roof Machine For Weather-Resistant Roofing

Product Description

Product Application

Machine name: Plastic PVC Hollow Roof Tile Making machine
Finshed product : Plastic Hollow roofing , PVC composite roofing , Plastic corrugated roofing, Double Wall roofing

Product application: Plastic Corrugated tile are used for Roofing, can be used for factories, warehouses, sheds, farmers market, hoardings, walls, temporary shops, sheds and other very suitable insulation

Product features:
PVC+ASA glazed/corrugated hollow composite resin tile should be the IDEAL REPLACEMENT of conventional asbestos and metal G.I. sheets which are not resistant to corrosion and weather under the high cost and short service life.
This new PVC composite roof tile production adopted advanced multilayer CO-EXTRUSION technology which well combine the different functions of raw materials(PVC+ASA) so that the tile can be anti-corrosive, fire retardant, eco-friendly, more durable, tenacious, easy to install and move, light weight as well as cost effective in installation (as less steel and less overlap), as per the efficiency and benefits it provides.
Apart from its numerous benefits, its salient features include heat insulation up to 35% (highly energy efficient) and it can withstand temperature up to 70 degrees Celsius to - 40 degrees Celsius which is very much suitable for YOUR MARKET.

Machine List
No.	Name	Qty.	Remark
1	Screw loader for SJZ 80/156 extruder	1
2	SJZ 80/156 conical twin-screw extruder	1	For the PVC layer
3	Vacuum loader for SJ50 extruder	1
4	Drying hopper for SJ50 extruder	1
5	SJ50/30 single screw extruder(ASA)	1	For the ASA layer
6	Mould unit	1
7	Distributor	1
8	Forming table and calibration mould	1
9	Haul off unit	1
10	Cutter	1
11	Stacker	1

1. SJSZ-80/156 conical twin screw extruder with Automatic Feeding system

2. PVC Hollow Roof Mould

3.Vacuum calibration platform

4. Haul- off Machine & cutter machine

Auxiliary Machine
12	Crusher	1	Power:11kw,22kw,30kw
13	Pulverizer	1	Power:45kw,55kw,75kw
14	SRL-Z300/600 Mixer unit	1	Capacity : 450-550kg/h
15	Screw loader for SRL-Z 300/600 Mixer	1

ELECTRIC BRAND SHOW

Packaging & Shipping

250kw UPVC PVC Roof Tile Machine Automatic Roof Tile Manufacturing Machine Customized 11

Certifications

250kw UPVC PVC Roof Tile Machine Automatic Roof Tile Manufacturing Machine Customized 12

Tag:

Certification:	CE ISO

Minimum Order Quantity:	2 sets
Price:	CN¥793,650.00/sets >=2 sets
