Detail Information

Name:	Board Making Machine	Plastic Processed:	PVC, WPC
Application:	Sheet, Plates	Screw Design:	Double-screw
Twin Screw Type:	Counter-rotating Conical Twin-screw	Screw Material:	38CrMoALA
Screw Diameter (mm):	80	Screw L/d Ratio:	156:1
Screw Speed (rpm):	40 Rpm	Place Of Origin:	Shandong, China
Brand Name:	Deerma	Voltage:	380V/3P/50HZ
Dimension(lwh):	25253m	Warranty:	1 Year
Key Selling Points:	Multifunctional	Video Outgoing-inspection:	Provided
Core Components:	Motor, Pump, PLC, Gearbox	Machinery Test Report:	Provided
After-sales Service Provided:	Engineers Available To Service Machinery Overseas, Video Technical Support, Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Online Support	Model Name:	WPC Furniture Board Making Machine/production Line
Processed Type:	Extruding Machine	Plastic Processed:	PVC Resin
Product Thickness:	3-45cm	Product Width:	1220-2050mm
Output Capacity:	200-500kg/h	Product Application:	Furniture,building Plate,house Decorating Ect.
Machine Control:	PLC	Guarantee Time:	12months
After Warranty Service:	Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service	Local Service Location:	None
Marketing Type:	Ordinary Product	Condition:	New
Showroom Location:	None	Applicable Industries:	Building Material Shops, Manufacturing Plant, Construction Works
Warranty Of Core Components:	1 Year	Weight:	13Tons
Port:	Qingdao
Highlight:	Furniture Board Making Machine , Board Making Machine 200kg/h , 500kg/h WPC Board Production Line

Product Description

38CrMoALA Screw Material WPC Furniture Board Making Machine/Production Line For 3-45cm Product Thickness In High Demand

Production Description

High efficiency conical twin screw extruder.
It can produce rigid pvc wpc crust/skinning foam board machine.
The thickness is from 3mm to 45mm, width is from 1220mm to 2050mm.
This sheet is mostly used in transportation , advertisement,construction furniture industry ect.

Production Line

Main Composition of PVC foam board making machine/extrusion line

Item	Quantity
SJSZ80/156 conical twin screw extruder	one set
Electric cabinet	one set
Nose and die mold	one set
Forming machine	one set
Water chiller	one set
Cooling bracket	one set
Tractor machine	one set
Longitudinal cutter	one set
Dust vacuuming device	one set
Traverse cutter	one set
Automatic discharge	one set
Other auxiliary tools and parts	one set

1.SJSZ80/156 Conical Twin Screw Extruder

2.Electric Cabinet

Furniture Board Making Machine 200kg/h - 500kg/h WPC Board Production Line 2

3.Die Mold

4.5.Forming machine with water chiller

6.Cooling bracket

7.8.Tractor machine with Longitudinal cutter

9.Traverse cutter

Furniture Board Making Machine 200kg/h - 500kg/h WPC Board Production Line 7

Application

These pvc foam board is mostly used in transportation , advertisement, funiture industry and so on.
Products characteristics
1) Water proof, anti-flaming, damp proof, rot proof, mothproof, light weight, keep temperature, sound and heat insulation and shock proof etc.
2) Color-way is not changed long time and not easy to aging under radiation resistance;
3) This product can be manufactured by general wood processing tools; It can be drilled, sawed, nailed and dig It is the same as wood manufacture processing, even better than wood. It is the best substitute to wood, aluminum and composite product.
4) It can be welded as per general welding stipulation and also stick to other PVC materials;
5) Smooth surface and easy to print.

Furniture Board Making Machine 200kg/h - 500kg/h WPC Board Production Line 8

Certification

After Services

1.Our company will provide relevant information on various technology and business consulted by customers. If clients want to visit our company, we will offer all they need for convenience.

2.After signing contract, company designs groundsill installation chart for water, electricity and gas of equipment basing on real condition and customers’ requirements and provides detail order list and matching manufacturer for reference for customer.

3.After equipment arrival, our service personnel will arrive at posted locale for installation, debugging, training and technology transfer till customers can operate independently and manufactures eligible product. Service personnel have to arrive at customer’s locale in time when we provide service for client again.
